ACEDES 英制齿轮滚刀/齿轮加工工具

TYPE

RANGE

DIA

LENGTH

BORE

T2.5Se

15-20T

2.25

2.25

22mm

T2.5Se

15-20T

1.875

1.875

0.75

AT3

51-114T

1.875

1.875

0.75

AT3

115-200T

1.875

1.875

0.75

T5SE

15-20T

2.5

2.5

1.25

T5

21-50T

2.5

2.5

1.25

T5

51-114T

2.5

2.5

1.25

T10SE

16-20T

3

3

1.25

T10

21-45T

3

3

1.25

T10

46-114T

3

3

1.25

T10

115T+

3

3

1.25

PITCH

RANGE

DIA

LENGTH

BORE

'MXL'

0.08

12-23

1.875

1.25

0.75

0.08

24+

1.875

1.25

0.75

'XL'

0.2

10+

2.5

2.5

1.25

0.2

10+

2.5

2.5

27mm

'L'

0.375

10+

2.5

2.5

1.25

'H'

0.5

20+

2.75

2.75

1.25

'XH'

PITCH

CODE

DIA

LENGTH

BORE

RANGE

3mm

BH496

32mm

25mm

10mm

9-13

3mm

BH496

32mm

25mm

0.5

9-13

3mm

AH822

32mm

25mm

0.5

81+

3mm

BH496

51mm

51mm

27mm

9-13

3mm

AH752

51mm

51mm

27mm

14-25

3mm

BH497

51mm

51mm

27mm

26-80

3mm

AH822

51mm

51mm

27mm

81+

3mm

BH496

2

2

0.75

9-13

5mm

AH757

32mm

25mm

0.5

80+

5mm

AH755

51mm

51mm

27mm

11-16

5mm

AH754

51mm

51mm

27mm

17-31

5mm

AH756

51mm

51mm

27mm

32-79

5mm

AH757

51mm

51mm

27mm

80+

5mm

AH755

2

2

0.75

11-16

5mm

AH757

2

2

0.75

80+

8mm

PG2055

3

3

1.25

18-27

8mm

PG2036

3

3

1.25

28-89

8mm

PG2051

3

3

1.25

90+

8mm

PG2055

3

3

32mm

18-27

8mm

PG2036

3

3

32mm

28-89

8mm

PG2051

3

3

32mm

90+

14mm

PG2058

3

3

1.25

28-40

14mm

PG2059

3

3

1.25

41-89

14mm

PG2060

3

3

1.25

90+

14mm

PG2058

3

3

32mm

28-40

14mm

PG2059

3

3

32mm

41-89

14mm

PG2060

3

3

32mm

90+

20mm

BH996

3.5

3.5

1.25

32-45

20mm

AH1002

3.5

3.5

1.25

46-100

20mm

AH1023

3.5

3.5

1.25

101+

0.375"

AH938

3

3

1.25

17-26

0.375"

AH939

3

3

1.25

27-52
